C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 58 –
Configuration Configures global settings, including status, voice VLAN ID,
VLAN aging time, and traffic priority; also configures port
settings, including the way in which a port is added to the
Voice VLAN, and blocking non-VoIP addresses
181
OUI Maps the OUI in the source MAC address of ingress packets
to the VoIP device manufacturer
183
QoS 185
Ports Configures default traffic class, user priority, queue mode,
and queue weights
185
DSCP Remarking Remarks DSCP values to standard CoS classes, best effort,
or expedited forwarding
187
QoS Control List Configures QoS policies for handling ingress packets based
on Ethernet type, VLAN ID, TCP/UDP port, DSCP, ToS, or
VLAN priority tag
189
Rate Limiters Configures ingress and egress rate limits 191
Storm Control Sets limits for broadcast, multicast, and unknown unicast
traffic
193
Mirroring Sets source and target ports for mirroring 194
UPnP Enables UPNP and defines timeout values 195
Monitor 197
System 197
Information Displays basic system description, switch’s MAC address,
system time, and software version
197
CPU Load Displays graphic scale of CPU utilization 198
Log Limits the system messages logged based on severity;
displays logged messages
199
Detailed Log Displays detailed information on each logged message 200
Ports 201
State Displays a graphic image of the front panel indicating active
port connections
201
Traffic Overview Shows basic Ethernet port statistics 201
QoS Statistics Shows the number of packets entering and leaving the
egress queues
202
Detailed Statistics Shows detailed Ethernet port statistics 203
Security 205
Access
Management
Statistics
Displays the number of packets used to manage the switch
via HTTP, HTTPS, SNMP, Telnet, and SSH
205
Network
Port Security
Switch Shows information about MAC address learning for each
port, including the software module requesting port security
services, the service state, the current number of learned
addresses, and the maximum number of secure addresses
allowed
206
Table 4: Main Menu (Continued)
Menu Description Page
