Connector (P3) Pin Sub-D Pin Signal Pin Sub-D Pin Signal
P3 65 P3B 28 IDX(3) P3 66 P3A 28 IDX(3)
P3 67 P3B 12 GND P3 68 P3A 12 GND
P3 69 P3B 45 PHI0(4) P3 70 P3A 45 PHI0(4)
P3 71 P3B 29 PHI90(4) P3 72 P3A 29 PHI90(4)
P3 73 P3B 13 IDX(4) P3 74 P3A 13 IDX(4)
P3 75 P3B 46 GND P3 76 P3A 46 GND
P3 77 P3B 30 PHI0(5) P3 78 P3A 30 PHI0(5)
P3 79 P3B 14 PHI90(5) P3 80 P3A 14 PHI90(5)
P3 81 P3B 47 IDX(5) P3 82 P3A 47 IDX(5)
P3 83 P3B 31 GND P3 84 P3A 31 GND
P3 85 P3B 15 CANL P3 86 P3A 15 GND
P3 87 P3B 48 CANH P3 88 P3A 48 GND
P3 89 P3B 32 GND P3 90 P3A 32 GND
P3 91 P3B 16 VCC2 (+ 5 V) P3 92 P3A 16 VCC2 (+ 5 V)
P3 93 P3B 49 VCC2 (+ 5 V) P3 94 P3A 49 VCC2 (+ 5 V)
P3 95 P3B 33 VCC3 (+ 5 V) P3 96 P3A 33 VCC3 (+ 5 V)
P3 97 P3B 17 VCC3 (+ 5 V) P3 98 P3A 17 VCC3 (+ 5 V)
P3 99 P3B 50 GND P3 100 P3A 50 GND
The CAN bus lines (CANH, CANL) are not terminated with
a resistor on the DS1103.
The DS1103 provides three VCC lines. The total load of
every VCC line (VCC1, VCC2, VCC3) must not exceed 500
mA.
For details on the VCC lines refer to Power Supply Outputs
on page 162.
Because the pin numbering used for Sub-D connectors is not
standardized, the following illustrations show the numbering scheme
used (viewed from the top of a female connector)
Do not rely on the numbers written on Sub-D
connectors.
Pinout of Sub‑D connectors
