Additional equipment
Service Instructions 755 A/756 A - 00.0 - 02/2019 225
Fig. 221: Assembling the tape feeder and inserting the reinforcement strip (3)
6. Feed the reinforcement strip (5) into the guide (10).
7. Push up the hook (9) and the reinforcement strip (5) until the
reinforcement strip (5) juts out through the cutout in the fabric
sliding plate.
Information
You can use the knurled screws (1) and (8) to adjust the guide (10) to
the width of the reinforcement strip (5).
8. Switch on the machine.
9. Press the button.
 The reinforcement strip (5) is cut to the correct length.
Information
The tape projection at seam beginning and seam end can be set in
the Program parameters menu Program parameters > Automatic
tape feeder ( p. 329).
(1) - Knurled screw
(5) - Reinforcement strip
(8) - Knurled screws
(9) - Hook
(10) - Guide
