DURKOPP ADLER 755 A

To Next Page

To Previous Page

Programming

312 Service Instructions 755 A/756 A - 00.0 - 02/2019

Programmable marking lamps X-axis

Fig. 294: Programmable marking lamps X-axis

To program the programmable marking lamps for the X-axis:

1. Press the button , or .

 The desired marking lamp moves to the corresponding position.

2. Press the button , or .

3. Enter the desired correction value using the numeric keypad.

4. Confirm with OK.

Symbols Meaning

Programmable marking lamps in longitudinal direction On/Off

Set programmable marking lamp seam beginning

• -120 - 120

Set programmable marking lamp seam center

• -120 - 120

Set programmable marking lamp seam end

• -120 - 120
