Programming

Service Instructions 755 A/756 A - 00.0 - 02/2019 313

Programmable marking lamps Y-axis

Fig. 295: Programmable marking lamps Y-axis

To program the programmable marking lamps for the Y-axis:

1. Enter the desired correction value using the numeric keypad.

2. Confirm with OK.

Symbols Meaning

Programmable marking lamps in crosswise direction On/Off

Set programmable marking lamp Y-axis

• -120 - 120

Default Chapter3
