Programming
318 Service Instructions 755 A/756 A - 00.0 - 02/2019
Middle knife parameters
 The display switches to Middle knife parameters.
Fig. 300: Middle knife parameters
To set the middle knife parameters:
1. Press the desired button.
2. Enter the desired value using the numeric keypad.
3. Confirm with OK.
Symbols Meaning
Middle knife On/Off
Set middle knife correction seam begin.  p. 319
• -9.9 mm - 9.9 mm
Set middle knife correction seam end  p. 319
• -9.9 mm - 9.9 mm
Automatic speed adjustment On/Off
• if automatic speed adjustment is enabled, the option
Set speed middle knife is not available
Set speed middle knife manually
• 100 RPM - 2000 RPM
• if this option is enabled, the option Automatic speed
adjustment On/Off is not available
Set middle knife position at insertion
• 0 mm - 30 mm
