Programming

340 Service Instructions 755 A/756 A - 00.0 - 02/2019

To select downholder mode:

1. Press the desired button.

Information

The numbering of the buttons downholder , vacuum and waist-

band clamp in the lower half of the display changes with the selected

setting.

1: Waistband clamp

2: Downholder

3: Vacuum
