Programming
344 Service Instructions 755 A/756 A - 00.0 - 02/2019
Selecting pedal mode
The display switches to Select pedal mode
Fig. 320: Selecting pedal mode
To select pedal mode:
1. Press the desired button.
Symbols Meaning
Press pedal 1 x and keep it there
the loading process is completed without stop
Push pedal after each step
Vacuum, downholder and transport clamp are each triggered with
one step during the loading process
the sewing process starts after the flap clamps have been lowered
Transport clamp start after pushing pedal
Vacuum, downholder and transport clamp are each triggered with
one step during the loading process
The flap clamps can be opened or closed again after the flap clamps
have been lowered, and the sewing process is started
