Programming
Service Instructions 755 A/756 A - 00.0 - 02/2019 343
Valve Y32 Valve Y124
Mode Method Position Blowing ON
Blowing OFF
Position Blowing ON
Blowing OFF
Sequence
Mode 0 - active - active Function off Mode 1 A-B-F Blow tube
in folding plate
Folding plate closed
Needles ON
Blow tube in flap clamps
Flap clamps closed
Needles ON Blow pocket bag and/or piping to the seam begin-
ning simultaneously.
Mode 2 A-B-F Blow tube
in folding plate
Folding plate closed
Flap clamps closed
Blow tube in flap clamps
Flap clamps closed
Needles ON Blow pocket bag and piping alternately up to
seam beginning.
Mode 3 B-F Blow tube
in folding plate
Lower folder 10 mm
after load- ing posi- tion
Blow tube in flap clamps
Flap clamps closed
10 mm after loading posi- tion
Blow pocket bag and/or piping briefly. Blow piping already while folder is lowering.
Mode 4 B-F Blow tube
in folding plate
Lower folder Flap
clamps closed
Blow tube in flap clamps
Flap clamps closed
Needles ON Blow pocket bag and piping alternately up to
seam beginning. Blow piping already while folder is lowering.
Mode 5 B Blow tube
in flap clamp right
Flap clamp closed
Needles ON
Blow tube in flap clamp left
5 mm after load- ing position
Needles ON Blow pocket on flap.
Mode 6 A-B-F Blow tube
in folding plate
Folding plate closed
180 mm after load- ing posi- tion
Blow tube in flap clamps
Flap clamps closed
Needles ON Blow pocket bag and/or piping at the same time.
Blow piping after path.
Mode 7 A-B-F Blow tube
in folding plate
20 mm after loading posi- tion
180 mm after load- ing posi- tion
Blow tube in flap clamps
10 mm after loading position
180 mm after loading posi-
tion
Bl
ow pocket bag and/or piping after paths.
