Programming

342 Service Instructions 755 A/756 A - 00.0 - 02/2019

To select blowing mode:

1. Press the desired button.

Information

The numbering of the buttons folding plate , flap clamp and

lower pickup folder in the lower half of the display changes with

the selected setting.
