Programming

388 Service Instructions 755 A/756 A - 00.0 - 02/2019

Set and test needle transport

 The display switches to Test needle transport.

Fig. 354: Test needle transport

To test the needle transport:

1. Press the button.

 Reference run is carried out.

2. Press the desired button.

Symbol Meaning

Adjust needle transport  p. 389

Reference

Step motor On/Off

Set motor drive position

• +3.5: Needle transport in sewing direction

• -3.5: Needle transport against sewing direction

Split needle bar On/Off
