Programming

Service Instructions 755 A/756 A - 00.0 - 02/2019 397

Adjust programmable marking lamps (crosswise)

 The display switches to Adjust programmable marking lamps.

Fig. 363: Adjust programmable marking lamps (crosswise)

Symbol Meaning

Adjust programmable marking lamp position 1

• Value range -100 - 100

Adjust programmable marking lamp position 2

• Value range -100 - 100

Adjust programmable marking lamp position 3

• Value range -100 - 100
