Programming
Service Instructions M-TYPE DELTA - 00.0 - 12/2019 141
Mode
Setting defining which roller is supposed to
run.
Not driven
Both rollers freewheel
passively; mechanical
coupling only.
Top
The upper roller runs
actively under power.
Top + Bottom
Both wheels run actively
under power.
Feeding method
only visible if option Top / Top + Bottom
has been selected under Mode
continuous = even
transport
intermittent =
transport adapted to the
rhythm of the feed dog
Start
only visible if the check box Feeding
method has been turned on
Setting of the start and
stop angle under Start/
Stop has been adapted
to the machine.
The values should not
be changed
Value range
0 - 359 [°]
Stop
only visible if the check box Feeding
method has been turned on
Setting of the start and
stop angle under Start/
Stop has been adapted
to the machine.
The values should not
be changed
Value range
0 - 359 [°]
Pressure
Set the puller pressure
Value range
Yes/No/
No Pressure with HP
(2
nd
foot stroke)
Switch off Value range
On/Off
Always on Value range
On/Off
Icon Menu items Value range
