Service Instructions M-TYPE DELTA - 00.0 - 12/2019 229
25.3 Basic setting of the machine
If you wish to perform a complete recalibration of the machine, use the fol-
lowing values as orientation:
Setting Preset value
Customer
preset
Current
machine
mechanical
Stitch regulator gear  p. 41
Sewing foot lift  p. 68
Sewing foot pressure  p. 156
Timing 2 mm
Needle guard  p. 57
Feed dog stroke eccentric  p. 37
Feed dog
pusher eccentric
 p. 38
Sewing foot stroke eccentric  p. 39
Feed dog height 0.9 mm
Feed dog position  p. 45
Compensating feet  p. 63
Needle thread regulator  p. 71
Thread tensioning spring travel  p. 73
Thread tensioning spring
tension
90 gr.
 p. 74
Hook thread tension* 100 gr.
Needle thread pretension
(with main tension open)
1, 3
60 gr.
electronic
Stitch length V/O/R  p. 136
Needle thread tension
2, 3
200 gr.
1
Material thickness detection  p. 145
* Factory calibration depending on equipment with Serafil white 40Nm, 30Nm or 20Nm
1
Factory calibration always with Serafil black 30 Nm
2
Pretension must always be set mechanically first!
3
measured without needle thread regulator and thread tensioning spring
required tools:
• Locking peg (included, part number 0867 104950)
• Spring balance 600 gr. (part number 0APP 001503)
