Thread trimmer (FA)
78 Service Instructions M-TYPE DELTA - 00.0 - 12/2019
13 Thread trimmer (FA)
13.1 Adjusting the height of the thread-pulling knife
Fig. 64: Adjusting the height of the thread-pulling knife
WARNING
Risk of injury from sharp parts!
Cutting injuries may be sustained.
Switch off the machine before adjusting the thread
trimmer.
WARNING
Risk of injury from moving parts!
Crushing possible.
Switch off the machine before adjusting the thread
trimmer.
(1) - Counter blade
(2) - Thread-pulling knife
(3) - Threaded pin
(4) - Lever
(5) - Screw
(6) - Hook bearing
(7) - Set collar
③
⑦
①
②
④
③
⑤
⑥
