DURKOPP ADLER D867 M-Type Delta User Manual

Technical data
224 Service Instructions M-TYPE DELTA - 00.0 - 12/2019
24.1 Data and characteristic values
24.2 Requirements for fault-free operation
Compressed air quality must conform to ISO 8573-1: 2010 [7:4:4].
Technical data Unit
D867-190922 D867-190929 D867-190942 D867-190945 D867-190949 D867-290922 D867-290942 D867-290945
Type of stitches Double lockstitch 301
Hook type vertical (XL),
large
vertical (XXL),
extra large
vertical
(XL),
large
vertical
(XXL),
extra large
Number of needles 1 2
Needle system 134-35
Needle strength [Nm] 90 - 180
Thread strength [Nm] 120/3 - 10/3 (short thread cutter, KFA max. 15/3)
Stitch length [mm] 12/12
Speed maximum
[min
-1
]
4000 3500
Speed on delivery
[min
-1
]
3600 3500 3000
Mains voltage [V] 230 V
Mains frequency [Hz] 50/60
Operating
pressure
[bar] 6
(Compressed air only required in combination with optional
additional equipment)
Length [mm] 720
Width [mm] 220
Height [mm] 460
Weight [kg] 56 58
