19.4.14 Setting the Edge guide parameters
Various settings can be made for the edge guide (motor driven).
The possibilities are explained in more detail in the table
NOTICE
Property damage may occur!
Sewing feet, needle, edge guide and sewing equipment can be
damaged.
ALWAYS check the distance to the edge guide and input the correct
value after changing the sewing equipment.
Icon Menu items Value range
Edge guide • Value range
On/Off
Edge Guide Mode • Value range
1-axis Internal/
1-axis External/
2-axis External
Internal: the stepper
motor card of the edge
guide is housed inside
the control
External: the stepper
motor card of the edge
guide is located on the
component
Motor driven • Value range
On/Off
Speed
Travel speed of the edge guide
• Value range
0500 - 60000 [Hz]
