Sewing motor
Service Instructions M-TYPE DELTA - 00.0 - 12/2019 107
18 Sewing motor
18.1 Overview of the components
Fig. 90: Overview of the components
DANGER
Risk of injury from electricity!
Unprotected contact with electricity can result in
serious injuries or death.
Work on the electrical system must ONLY be
carried out by qualified electricians or appropriately
trained and authorized personnel.
ALWAYS pull the power plug before working on the
electrical equipment.
WARNING
Risk of injury from moving parts!
Crushing possible.
The machine may only be disassembled and
assembled by trained specialists.
(1) - Support plate
(2) - Motor
(3) - Toothed belt wheel
(4) - Toothed belt
(5) - Handwheel
(6) - Tensioning roller
