DURKOPP ADLER D867 M-Type Delta User Manual

Adjusting feed dog and needle bar linkage
44 Service Instructions M-TYPE DELTA - 00.0 - 12/2019
7 Adjusting feed dog and needle bar linkage
Proper setting
At stitch length 0 the feed dog is centered on the side relative to the throat
plate. The needle pierces into the center of the feed dog on the side and
in sewing direction.
Information
The steps necessary to adjust the feed dog feed movement, the feed
dog lift movement and the compensating weight are described in the
chapter Basic eccentric settings ( p. 36).
WARNING
Risk of injury from moving parts!
Crushing possible.
Move the machine into the service routine before
adjusting the feed dog.
WARNING
Risk of injury from moving parts!
Crushing possible.
Move the machine into the service routine before
aligning the needle bar linkage.
