DURKOPP ADLER D867 M-Type Delta User Manual

Programming
140 Service Instructions M-TYPE DELTA - 00.0 - 12/2019
19.4.12 Setting the Needle cooling parameters
Various settings can be made for the needle cooling. The possibilities are explained in more
detail in the table.
19.4.13 Setting the Puller parameters
The puller is a piece of optional additional equipment and designed to
support the feed of the sewing material. When the puller is activated, the
following settings can be made.
Icon Menu items Value range
Mode • Value range
Off, On, Related to
sewing speed, Edge
trimmer
t Delay
Lag time, after which the needle cooling is
deactivated.
only visible if the
mode On, Related to
sewing speed or Edge
trimmer is activated
• Value range
00.0 - 10.0 [ms]
Cool Speed
Speed at which the needle cooling is acti-
vated.
only visible if the
mode On, Related to
sewing speed or Edge
trimmer is activated
• Value range
0000 - 3800 [rpm]
Icon Menu items Value range
Puller • Value range
On/Off
Auto
Mode for raising the puller automatically
• Value range
During sewing foot lift/
On Tack/
During bartacking and
when sewing foot is
lifted
Raise by
quick stroke adjustment
• Value range
On/Off
Delay
Lowering of the roller after seam
beginning; depends on stitch length and
application.
• Value range
000.0 – 999.9 [mm]
