Working basis
Service Instructions M-TYPE DELTA - 00.0 - 12/2019 13
3 Working basis
3.1 Order of the adjustments
Order
The setting positions for the machine are interdependent.
Always comply with the order of individual adjustment steps as specified.
It is absolutely essential that you follow all notices regarding prerequisites
and subsequent settings that are marked with in the margin.
3.2 Laying the cables
Ensure that all cables are laid in the machine such that the function of
moving parts is not hampered.
To lay the cables:
1. Lay any excess cabling neatly in proper cable snakes.
2. Bind together the cable loops with cable ties.
Important
Tie loops wherever possible to fixed parts.
The cables must be secured firmly.
3. Cut off any overlapping cable ties.
NOTICE
Property damage may occur!
Risk of machine damage from incorrect order.
It is essential to follow the working order specified in these
instructions.
NOTICE
Property damage may occur!
Excess cables can impair the functioning of moving machine parts.
This impairs the sewing function and can result in damage.
Lay excess cable as described above.
