Programming
Service Instructions M-TYPE DELTA - 00.0 - 12/2019 149
19.4.24 Setting the Scanner parameters
The scanner can be activated or deactivated. A barcode scanner offers a
way to directly select a seam program.
The following types of barcodes can be read using the scanner:
• Code 128
• UCC EAN 128
• Code 39
The barcode types can be created with freeware software.
Important
The barcode must be composed of 3 to 32 bars. The 3-digit number of
the program (001 to 999) must be contained in the barcode.
Refer to the Appendix ( p. 225) for a few barcode examples that you
can use.
Information
The scanner also supports other types of barcodes. For a list of all sup-
ported barcodes and information on how to configure them, refer to the
Operating Instructions of the scanner manufacturer.
19.4.25 Setting the Interface parameters
The interfaces can be used for the scanner. The parameter is active if a
scanner is connected.
It is possible to define additional settings for the interface. The possibilities
are explained in more detail in the table.
Icon Menu items Value range
Scanner • Value range
On/Off
Icon Menu items Value range
BDE
Mode • Value range
Off/Scanner
Baudrate
Transmission rate of the scanner
• Value range
9600 - 250000
