Programming

170 Service Instructions M-TYPE DELTA - 00.0 - 12/2019

Fig. 119: Exporting data (3)

6. Confirm selection.

Fig. 120: Exporting data (4)

 The data is exported.

Log files Messages of the machine:

• Most Recent Logs

• All Available Logs

Programs Seam programs: all created seam

programs, e.g.:

• 1 SETUP 1

• 2 SETUP 2

• 10 SEAM MANUAL

• 20 SEAM 20 AUTOMATIC

• 21 SQUARE

• 100 ORNAMENTAL SEAM

• 101 ORNAMENTAL SEAM

• 110 ORNAMENTAL SEAM

Customer Multimedia Own PDFs and videos

Icon Menu item Explanation
