DURKOPP ADLER D867 M-Type Delta User Manual

Working basis
Service Instructions M-TYPE DELTA - 00.0 - 12/2019 27
Important
Fig. 16: Disassembling the thread tension plate (2)
On 2-needle machines, the plug of connection X103 must be detached
from the PCB found behind the thread tension plate.
Assembling the thread tension plate
To assemble the thread tension plate:
1. On 2-needle machines: Connect the plug at connection X103.
2. Assemble the thread tension plate (3).
3. Tighten screws (1) and (2).
4. Slip plugs onto the PCB:
• Thread clamp: Connection X10 (optional)
• Thread tension: Connection X11
• Push button: Connection X12
