Position of the hook and needle
Service Instructions M-TYPE DELTA - 00.0 - 12/2019 55
To adjust the hook side clearance:
1. Execute the service routine Needle-Hook > Timing ( p. 14).
The software is used to define the necessary presettings on the
machine.
2. Lock the machine in place ( p. 32).
3. Open the throat plate slides ( p. 28).
4. Tilt the machine head ( p. 18).
5. Loosen the screws (4).
6. Loosen the threaded pin (2).
7. Move the hook support (3) sideways such that the distance between
the hook tip and the groove of the needle is no greater than 0.1mm.
Information
If the hook support can only be moved with difficulty, you can slightly
loosen the threaded pins (1).
8. Tighten the threaded pin (2).
9. Tighten the screws (4).
10. Finish the service routine.
Order
Then, check the following setting:
• Position of the needle guard ( p. 56)
