Position of the hook and needle
58 Service Instructions M-TYPE DELTA - 00.0 - 12/2019
2. Disassemble the throat plate ( p. 29).
3. Disassemble the feed dog ( p. 30).
4. Turn the handwheel and check how far the needle guard (3) pushes
the needle (1) away.
5. Turn the screw (2) such that the needle guard (3) just pushes the
needle (1) far away enough so that it cannot be touched by the hook tip.
• for pushing away more: Turn screw (2) counterclockwise
• for pushing away less: Turn screw (2) clockwise
6. Finish the service routine.
