User Manual Section 4
GFK-2958L May 2021
Detailed Descriptions of the Fieldbus Network Adapters 92
-20°C to +60°C (-4 °F to +140 °F)
-40°C to +85°C (-40 °F to +185 °F)
Air humidity (operation/transport)
5% to 95%, noncondensing as per IEC 61131-2
ESI file is available on the Support website
https://www.emerson.com/Industrial-Automation-
Controls/support for download and import into Programmer Tool
which supports EtherCAT. The ESI supporting a firmware release is
part of the firmware upgrade kit, also available on the Support
website.
4.3.4 Modifiable Parameters for EPXETC001
192.168.1.202; 192.168.2.202, 192.168.3.202,
192.168.4.202,
192.168.5.202
Behavior of outputs on fieldbus
error
All outputs off /
Enable substitute value/
Hold last value
Module behavior on hot swap
Continue data exchange /
Behavior like fieldbus error
disabled / enabled / enabled
†
Change requires restart of the network adapter.
4.3.5 RSTi-EP Status Messages
In addition to the process input data a network adapter status word as well as module
status bytes are transferred to the SPS. Thus, diagnostics and status messages can be read
directly.
The network adapter status word describes the status of the RSTi-EP station including the
following information:
Network Adapter Status Bits EPXETC001
Summarized module
diagnosis
Module diagnostic is present. A diagnosis is available for at least one module with
diagnostics functionality.
Reserve bit 1, currently not used
Reserve bit 2, currently not used
