Emerson PACSystems RSTi-EP - Modifiable Parameters for EP-5112

User Manual Section 5
GFK-2958L May 2021
Detailed Description of I/O Modules 231
5.17.3 Modifiable Parameters for EP-5112
Channel
Description
Options (†)
Default
Diagnostic alarm
disabled (0) / enabled (1)
disabled
0 ... 1
Filter time signal A
0.01ms [100 kHz] (0) /
0.017ms [50 kHz] (1) /
0.033ms [30 kHz] (2) /
0.1ms [10 kHz] (3) /
0.2ms [5 kHz] (4) /
0.5ms [2 kHz] (5) /
1ms [1 kHz] (6)
0.01ms
0 ... 1
Filter time signal B
0.01ms [100 kHz] (0) /
0.017ms [50 kHz] (1) /
0.033ms [30 kHz] (2) /
0.1ms [10 kHz] (3) /
0.2ms [5 kHz] (4) /
0.5ms [2 kHz] (5) /
1ms [1 kHz] (6)
0.01ms
0 ... 1
Process alarm overflow
disabled (0) / enabled (1)
disabled
0 ... 1
Process alarm underflow
disabled (0) / enabled (1)
disabled
0 ... 1
Process alarm comp. value
disabled (0) / enabled (1)
disabled
0 ... 1
Process alarm end value
disabled (0) / enabled (1)
disabled
0 ... 1
Counting mode
count endless (0) /
once - forward (1) /
once - backwards (2) /
once - no main direction (3) /
periodic - forward (4) /
periodic - backwards (5) /
periodic - no main direction (6)
count endless
0 ... 1
Comparison function
disabled (0) /
higher equal comparison value (1) /
lower equal comparison value (2) /
equal comparison value (3)
disabled
0 ... 1
Counter dir. signal B inv.
disabled (0) / enabled (1)
disabled
0 ... 1
Signal mode
Rotary transducer - single (0) /
Rotary transducer - double (1) /
Rotary transducer - quadruple (2) /
Pulse and Direction (3) /
disabled (4)
disabled
0 ... 1
Counter behavior internal gate
Interrupt counting (0) /
Cancel counting (1)
interrupt counting
0 ... 1
Setting value
-2147483648 to 2147483647
0
0 ... 1
End value
-2147483648 to 2147483647
2147483647
0 ... 1
Load value
-2147483648 to 2147483647
0
0 ... 1
Hysteresis
0 to 255
0
