User Manual Section 4
GFK-2958L May 2021
Detailed Descriptions of the Fieldbus Network Adapters 65
Output behavior fieldbus
error
All outputs off / activate
replacement values / retain last
value
Module behavior on hot
swap
Continue data exchange /
behavior as with fieldbus error
†
Change requires restart of the network adapter.
4.1.6 Supported Modules and Power Supplies
The following modules can be used with the current release of the RSTi-EP Profibus Network
Adaptor.
Digital Input, 4 Points, Positive Logic 24Vdc, 2-, 3-, or 4-Wire
Digital Input, 8 Points, Positive Logic, 24Vdc 2-Wire
Digital Input, 8 Points, Positive Logic, 24Vdc 3-Wire
Digital Input, 16 Points, Positive Logic, 24Vdc, 1-Wire
Digital Input, 4 Points, Positive Logic, 24Vdc, 2-, 3-, or 4-Wire, Time stamp
Digital Input, 16 Points, Negative Logic, 24Vdc 1-Wire
Digital Input, 4 Points 110/230Vac (65 – 277Vac), 2-Wire, Isolated
Digital Output, 4 Points, Positive Logic 24Vdc, 0.5A, 2-, 3-, or 4-Wire
Digital Output, 4 Points, Positive Logic 24Vdc, 2.0A, 2-, 3-, or 4-Wire
Digital Output, 4 Points, Positive/Negative Logic 24Vdc, 2.0A, 2-, 3-, or 4-Wire
Digital Output, 8 Points, Positive Logic, 24Vdc, 0.5A, 2-Wire
Digital Output, 16 Points, Positive Logic, 24Vdc, 0.5A, 1-Wire
Digital Output, 16 Points, Negative Logic, 24Vdc 1-Wire
Digital Relay Output Modules
Digital Relay Output, 4 Points, Positive Logic, 24 -–220 Vdc/Vac, 6A, 2-Wire
Solid-state Relay Output Module
Analog Input, 4 Channels Voltage/Current 16 Bits 2-, 3-, or 4-Wire
Analog Input, 4 Channels Voltage/Current 16 Bits with Diagnostics 2-, 3-, or 4-Wire
Analog Input, 4 Channels Voltage/ Current 16 Bits with Diagnostics 2-, 3-, or 4-Wire, Differential
Analog Input, 4 Channels Voltage/Current 12 Bits 2-, 3-, or 4-Wire
Analog Input, 8 Channels Current 16 Bits 2-, 3-, or 4-Wire
Analog Input, 8 Channels Current 16 Bits 2-, 3-, or 4-Wire, Channel Diagnostic
Analog Input, 4 Channels RTD 16 Bits with Diagnostics 2-, 3-, or 4-Wire
Analog Input, 4 Channels TC 16 Bits with Diagnostics 2-, 3-, or 4-Wire
Power Measurement Module, 8 Channels
Analog Output, 4 Channels Voltage/Current 16 Bits 2-, 3-, or 4-Wire
Analog Output, 4 Channels Voltage/Current 16 Bits with Diagnostics 2-, 3-, or 4-Wire
1 Channel High Speed Counter, AB 100 kHz 1 DO 24Vdc, 0.5A
