Emerson PACSystems RSTi-EP - 5.26 Analog Input Module EP-3664

User Manual Section 5
GFK-2958L May 2021
Detailed Description of I/O Modules 298
EtherCAT-EPXETC001
Process data for IO-Link devices
IO-Link port
Network adapters dependent
data widths
1)
Input-byte
Output-byte
Input-byte
Output-byte
16
16
18
18
1)
incl. 2 Byte module process data
Modbus-EPXMBE001/EPXMBE101
Process data for IO-Link devices
IO-Link port
Network adapters dependent
data widths
1)
Input-byte
Output-byte
Input-byte
Output-byte
0 … 62
0 … 62
2 ... 64
2 … 64
1)
incl. 2 Byte module process data
EtherNet/IP-EPXEIP001
Process data for IO-Link devices
IO-Link port
Network adapters dependent
data widths
1)
Input-byte
Output-byte
Input-byte
Output-byte
0 … 128
0 ...128
2 … 130
2 … 130
1)
incl. 2 Byte module process data
5.23.9 IO-Link Communication module EP-5324 event codes
Event Node
Description
0xC101
Overcurrent at transmitter
0xC102
Overtemperature at transmitted
0xC103
Undervoltage at VDD
0xC104
Undervoltage at VDDH
0xC105
Undervoltage at L+
0xC106
Overcurrent at L+ shunt
0xC201
Error at Data Storage EEPROM access
0xFF21
A new connection has been established between the Master
and the Device
0xFF22
The Device has not answered for three consequent Master
requests
0xFF23
DS header settings does not match with the read IDs
0xFF24
The DS buffer overflows
0xFF25
A DS parameter cannot be accessed
0xFF91
Request DS upload
