Emerson PACSystems RSTi-EP - Diagnostic Data EP-5111

User Manual Section 5
GFK-2958L May 2021
Detailed Description of I/O Modules 211
The output is switched off. The counter behaves in the same way as for Hold last value.
5.16.4 Diagnostic Data EP-5111
Name
Bytes
Bit
Description
Default
Error indicator
0
0
Module error
1
Internal error
2
External error
3
Channel error
4
External auxiliary supply error
5
Reserved
0
6
Reserved
0
7
Parameter error
Module type
1
0
Module Type
0x08
1
2
3
4
Channel information available
1
5
Reserved
0
6
Reserved
0
7
Reserved
0
Error byte 2
2
0-7
Reserved
0
Error byte 3
3
0-2
Reserved
0
3
Internal diagnostic FIFO full
4
Reserved
0
5
Reserved
0
6
Process alarm lost
7
Reserved
0
Channel type
4
0-6
Channel type
0x76
7
Reserved
0
Diagnostic bits per
channel
5
Number of diagnostic bit per channel
8
Number of channels
6
Number of similar channels per module
1
Channel error
7
0
Error at channel 0
1-7
Reserved
0
Channel error
8
8-15
Reserved
0
Channel error
9
16 - 23
Reserved
0
Channel error
10
24 - 31
Reserved
0
Channel 0 error
11
0
Hardware gate opened
1
Hardware gate closed
2
Overflow/underflow/end value
3
Comparison value reached
4
Latch value saved
5-7
Reserved
0
