Emerson PACSystems RSTi-EP - Process Data Inputs EP-5324

User Manual Section 5
GFK-2958L May 2021
Detailed Description of I/O Modules 295
5.23.6 Process Data Inputs EP-5324
Byte
Bit
Description
IB0
IX0.0
DI 1
IX0.1
DI 2
IX0.2
DI 3
IX0.3
DI 4
IX0.4
C/Q 1
IX0.5
C/Q 2
IX0.6
C/Q 3
IX0.7
C/Q 4
IB1
IX1.0
Process data IN valid IO-Link-Port 1
IX1.1
Process data IN valid IO-Link-Port 2
IX1.2
Process data IN valid IO-Link-Port 3
IX1.3
Process data IN valid IO-Link-Port 4
IX1.4
Error IO-Link-Port 1
IX1.5
Error IO-Link-Port 2
IX1.6
Error IO-Link-Port 3
IX1.7
Error IO-Link-Port 4
IB2 … Process data of the IO-Link device
1)
1)
The process data of the IO-Link device depend on which module has been chosen from the
device description file. The mapping of the IO-Link-devices depends on the length of their
process data and the parameter settings.
