Emerson PACSystems RSTi-EP - Process Alarm EP-3804

User Manual Section 5
GFK-2958L May 2021
Detailed Description of I/O Modules 366
Measurement
Range
Value in °C
0.1° resolution
Value in °F
0.1°/digit
Value in °K
0.1°K/digit
Range
-40
248
2,692
Underloading
23,190
32,767
25,922
Overloading
32,767
32,767
32,767
Line break,
cold compensation error
5.33.8 Process Alarm EP-3804
Name
Number of bytes
Function
High alarm
1
Bit 0: Upper limit exceeded channel 0
Bit 1: Upper limit exceeded channel 1
Bit 2: Upper limit exceeded channel 2
Bit 3: Upper limit exceeded channel 3
Bit 4 – 7: Reserved
Low alarm
1
Bit 0: Lower limit exceeded channel 0
Bit 1: Lower limit exceeded channel 1
Bit 2: Lower limit exceeded channel 2
Bit 3: Lower limit exceeded channel 3
Bit 4 – 7: Reserved
Timestamp
2
The two least significant bytes of the internal 32-bit timer
