User Manual Section 11
GFK-2958L May 2021
Disassembly and Disposal 487
Section 11: Disassembly and Disposal
11.1 Disassembling the RSTi-EP Station
WARNING
Explosion Risk - Prior to starting work, ensure that there is not a potentially explosive
atmosphere.
CAUTION
Dangerous contact voltage - Carry out all disassembly work on the RSTi-EP station only
when the power supply is disconnected. Ensure that the place of installation (switch
cabinet and such) has been disconnected from the power supply.
•
To disassemble the RSTi-EP station
1.
Remove all cables and lines.
2.
Remove the end bracket marker (if present).
3.
Unfasten the mounting screw on the right-hand end bracket.
4.
Slide the end bracket with the end plate to the right and remove both from the
DIN rail.
You can now disassemble the modules and the field-bus network adapter either
individually or in groups of three to four modules.
5.
Press all the release levers of a module group towards the mounting plate so that
they click into place.
6.
Slide the module group to the right and remove it from the DIN rail.
7.
Repeat the above procedure for all remaining modules/ module groups.
8.
To disassemble the field-bus network adapter, open both release levers and
remove it from the DIN rail.
9.
Unfasten the mounting screw on the left-hand end bracket and remove it.
10.
Observe the instructions for proper disposal.
11.2 Disposing of the RSTi-EP Station
Products in the RSTi-EP series are subject to WEEE (EU Directive
2002/96 EC), which regulates the collection and recycling of electrical
and electronic equipment. Ensure that disassembled products are
properly disposed of.
