Emerson PACSystems RSTi-EP - Specifications: EPXEIP001

User Manual Section 4
GFK-2958L May 2021
Detailed Descriptions of the Fieldbus Network Adapters 119
4.5.3 Specifications: EPXEIP001
Specification
Description
System data
Connection
2 x RJ-45
Fieldbus protocol
EtherNet/IP
Process image
Process Data
max. 2 x 494 Bytes
Parameter data
max. 64 x 64 Bytes
Diagnostic data
max. 64 x 47 Bytes
Number of modules
max. 64 active
Configuration interface
Micro USB 2.0
Transfer rate
Fieldbus
10 Mbps/100 Mbps
RSTi-EP system bus
Max. 48 Mbps
Supply
Supply voltage for system and inputs
20.4V – 28.8V
Supply voltage for outputs
20.4V – 28.8V
Max. feed-in current
1)
for input modules
10 A
Max. feed-in current
1)
for output modules
10 A
Current consumption from system current path
I
SYS
112 mA
Temperature Data
1)
< HW 02.00.00
Operation
(Horizontal installation)
-20 °C to +60 °C / - 4 °F ... +140 °F (2 x 8 A power supply)
-20 °C to +55 °C / - 4 °F ... +131 °F (2 x 10 A power supply
Operation
(Vertical installation)
-20 °C to +55 °C / - 4 °F ... +131 °F (2 x 6 A power supply)
-20 °C to +50 °C / - 4 °F ... +122 °F (2 x 8 A power supply)
Connection data
Type of connection
PUSH IN
Conductor cross-section
Single-wired, fine-wired
0.14 – 1.5 mm2 (AWG 26 – 16)
General data
Operating temperature
-20°C to +60°C (-4 °F to +140 °F)
Storage temperature
-40°C to +85°C (-40 °F to +185 °F)
Air humidity (operation/transport)
5% to 95%, noncondensing as per IEC 61131-2
Width
52 mm (2.05 in)
Depth
76 mm (2.99 in)
Height
120 mm (4.72 in)
Weight
223 (7.87 oz)
1)
Restrictions for the use in potentially explosive atmosphere: Only horizontal installation and max. 8 A power supply!
