Emerson PACSystems RSTi-EP - Process Data Outputs EP-2814; Digital Output Module EP-2714

User Manual Section 5
GFK-2958L May 2021
Detailed Description of I/O Modules 195
Name
Bytes
Bit
Description
Default
2
External error
3
Channel error
0
4
Error
5
Reserved
0
6
Reserved
0
7
Parameter error
Module type
1
0
Module Type
0x0F
1
2
3
4
Reserved
0
5
Reserved
0
6
Reserved
0
7
Reserved
0
Error byte 2
2
0-7
Reserved
0
Error byte 3
3
0-2
Reserved
0
3
Internal diagnostic FIFO full
0
4-7
Reserved
0
Channel type
4
0-6
Channel type
0x72
7
Reserved
0
Diagnostic bits per
channel
5
Number of diagnostic bit per channel
0
Number of channels
6
Number of similar channels per module
4
Channel error
7-10
0-31
Reserved
0
Channel 0 error
to
Channel 31 error
11
to
42
0–7
Reserved
0
Time stamp
43-46
Time stamp [
μ
s] (32-bit)
5.13.5 Process Data Outputs EP-2814
Byte
Bit
Description
OB0
OX0.0
DO0
OX0.1
DO1
OX0.2
DO2
OX0.3
DO3
OX0.4
reserved
OX0.5
reserved
OX0.6
reserved
OX0.7
reserved
5.14 Digital Output Module EP-2714
Figure 99: Digital Relay
Output Module EP-2714
