Emerson PACSystems RSTi-EP - Object Descriptions EPXEIP001: CIP Common Classes

User Manual Section 4
GFK-2958L May 2021
Detailed Descriptions of the Fieldbus Network Adapters 128
4.5.8 Object descriptions EPXEIP001: CIP Common Classes
Class
Attribute
Get
Set
NV
1)
Data Type
2)
Name
Description
hex
dez
Identity 0x01 (1)
Instance 0x00 (0)
0x01
1
x
UINT
Revision
Revision of this object
0x02
2
x
UINT
Max Instance
Highest possible instance of this
object
0x03
3
x
UINT
Number of Instances
Current number of instances
0x06
6
x
UINT
Max Class Attribute
ID of the last attribute of this
class in instance 0
0x07
7
x
UINT
Max Instance Attribute
ID of the last attribute of this
class in the other instances
Instance 0x01 (1)
0x01
1
x
x
UINT
Vendor ID
Vendor ID: 326
0x02
2
x
x
UINT
Device Type
General type of device: 0x0C
0x03
3
x
x
UINT
Product Code
Vendor assigned product code:
33492
0x04
4
x
x
Struct {USINT,
USINT}
Revision {Major, Minor}
Revision of the Network adapter
0x05
5
x
x
WORD
Device Status
Bit0: Owned;
Bit2= Configured;
Bit4-7: Extended device status;
Bit8: Minor recoverable fault;
Bit9: Minor unrecoverable fault;
Bit10: Major recoverable fault;
Bit 11: Major unrecoverable
fault;
Bit12-15: Extended device
status 2
0x06
6
x
x
UDINT
Serial Number
Serial number of the device; 32
Bit value
0x07
7
x
x
SHORT_STRING
Product Name
Product name: EPXEIP001
Message Router 0x02 (2)
Instance 0x00 (0)
0x01
1
x
UINT
Revision
Revision of this object
0x02
2
x
UINT
Max Instance
Highest possible instance of this
object
0x03
3
x
UINT
Number of Instances
Current number of instances
0x04
4
x
Struct {UINT,
Array of UINT}
Optional Attributes
List of optional attributes
0x05
5
x
Struct {UINT,
Array of UINT}
Optional Services
List of optional services
0x06
6
x
UINT
Max Class Attribute
ID of the last attribute of this
class in instance 0
