User Manual Section 4
GFK-2958L May 2021
Detailed Descriptions of the Fieldbus Network Adapters 129
Class
Attribute
Get
Set
NV
1)
Data Type
2)
Name
Description
hex
dez
0x07
7
x
UINT
Max Instance Attribute
ID of the last attribute of this
class in the other instances
Instance 0x01 (1)
0x01
1
x
Struct {UINT,
Array of UINT}
List of supported
objects
Number of objects; Class codes
0x02
2
x
UINT
Number of supported
connections
Number of supported
connections
Assembly 0x04 (4)
Instance 0x00 (0)
0x01
1
x
UINT
Revision
Revision of this object
0x02
2
x
UINT
Max Instance
Highest possible instance of this
object
0x03
3
x
UINT
Number of Instances
Current number of instances
0x04
4
x
Struct {UINT,
Array of UINT}
Optional Attributes
List of optional attributes
0x06
6
x
UINT
Max Class Attribute
ID of the last attribute of this
class in instance 0
0x07
7
x
UINT
Max Instance Attribute
ID of the last attribute of this
class in the other instances
Instances 0x65 ... 0x68 (101 ... 104)
0x03
3
x
x
Array of Byte
Data
Process data
0x04
4
x
UINT
Size
Size of process data
Instances 0x7A (122)
0x03
3
x
x
Array of Byte
Data
Configuration data
0x04
4
x
UINT
Size
Size of configuration data
Instances 0x7B (123)
0x03
3
x
x
Array of Byte
Data
Configuration data
0x04
4
x
UINT
Size
Size of configuration data
(static 400 BYTE)
Connection Manager 0x06 (6)
Instance 0x00 (0)
0x01
1
x
UINT
Revision
Revision of this object
0x02
2
x
UINT
Max Instance
Highest possible instance of this
object
0x03
3
x
UINT
Number of Instances
Current number of instances
0x04
4
x
Struct {UINT,
Array of UINT}
Optional Attributes
List of optional attributes
0x06
6
x
UINT
Max Class Attribute
ID of the last attribute of this
class in instance 0
0x07
7
x
UINT
Max Instance Attribute
ID of the last attribute of this
class in the other instances
Instance 0x01 (1)
0x01
1
x
x
UINT
Open Requests
Number of forward open
requests
0x02
2
x
x
UINT
Open Format Rejects
Number of forward open
requests, rejected
