Emerson PACSystems RSTi-EP - Page 144

User Manual Section 4
GFK-2958L May 2021
Detailed Descriptions of the Fieldbus Network Adapters 130
Class
Attribute
Get
Set
NV
1)
Data Type
2)
Name
Description
hex
dez
because of bad format
0x03
3
x
x
UINT
Open Resource Rejects
Number of forward open
requests, rejected because of
too few resources
0x04
4
x
x
UINT
Open Other Rejects
Number of forward open
requests, rejected because of
other reasons than format or
resource
0x05
5
x
x
UINT
Close Requests
Number of forward close
requests
0x06
6
x
x
UINT
Close Format Rejects
Number of forward close
requests, rejected because of
bad format
0x07
7
x
x
UINT
Close Other Rejects
Number of forward close
requests, rejected because of
other reasons than format
0x08
8
x
x
UINT
Connection Timeouts
Number of connection
timeouts
SNMP 0x52 (82)
Instance 0x00 (0)
0x01
1
x
UINT
Revision
Revision of this object
0x02
2
x
UINT
Max Instance
Highest possible instance of this
object
0x03
3
x
UINT
Number of Instances
Current number of instances
0x04
4
x
Struct {UINT,
Array of UINT}
Optional Attributes
List of optional attributes
0x06
6
x
UINT
Max Class Attribute
ID of the last attribute of this
class in instance 0
0x07
7
x
UINT
Max Instance Attribute
ID of the last attribute of this
class in the other instances
Instance 0x01 (1)
0x01
1
x
x
x
USINT
SNMP enable
1 = enable, 0 = disable
0x02
2
x
x
USINT
SNMP Version
1 = SNMPv1, 3 = SNMPv3, 31 =
SNMPv1+v3
0x03
3
x
x
x
Struct
{USINT,
STRING}
Trap 1
Destination of SNMP-traps,
Byte1: 0 = unconfigured,
1 = IP address; String: IP address
in form 123.123.123.123
0x04
4
x
x
x
Struct {USINT,
STRING}
Trap 2
Destination of SNMP-traps,
Byte1: 0 = unconfigured,
1 = IP address; String: IP address
in form 123.123.123.123
0x05
5
x
x
x
BOOL
Trap enable
1 = enable, 0 = disable
0x06
6
x
x
USINT
Trap Type
1 = TrapV1PDU, 2 = TrapV2PDU
(only with SNMPv3)
TCP IP Interface 0xF5 (245)
