For additional general data, refer to Section,
General Technical Data for I/O Modules.
5.44 Termination Kit EP-8301
Figure 234: Termination Kit EP-8301
Each RSTI-EP fieldbus network adapter is delivered together with a termination kit EP-8301.
This comprises two end brackets and an end plate. The end plate protects the contacts on
the last module at the end of the RSTI-EP station. The station is fixed to the DIN rail on both
sides via the end brackets.
5.44.1 Specifications EP-8301
