2 Channels PWM Output, Positive Logic,
24Vdc, 2 A
IO-Link Communication module, 4
Channels
Analog Input, 4 Channels
Voltage/Current 16 Bits 2-, 3-, or 4-Wire
Analog Input, 4 Channels
Voltage/Current 16 Bits with
Diagnostics 2-, 3-, or 4-Wire
Analog Input, 4 Channels Voltage/
Current 16 Bits with Diagnostics
2-, 3-, or 4-Wire, Differential
Analog Input, 4 Channels
Voltage/Current 12 Bits 2-, 3-, or 4-Wire
Analog Input, 4 Channels TC 16 Bits with
Diagnostics 2-, 3-, or 4-Wire
Analog Input, 8 Channels Current 16
Bits 2-, 3-, or 4-Wire
Analog Input, 8 Channels Current 16
Bits 2-, 3-, or 4-Wire, Channel
Diagnostic
Analog Output, 4 Channels Voltage/
Current 16 Bits 2-, 3-, or 4-Wire
Analog Output, 4 Channels Voltage/
Current 16 Bits with Diagnostics
2-, 3-, or 4-Wire
Analog Input, 4 Channels RTD 16 Bits
with Diagnostics 2-, 3-, or 4-Wire
Power Measurement Module, 8
Channels
1 Safe Feed-Input, 24 Vdc
2 Safe Feed-Inputs, 24 Vdc,
Programmable Delay
2 Safe Feed-Inputs, 24 Vdc
EtherNet/IP Network Adapter
Digital Input, 4 Points, Positive Logic
24Vdc, 2-, 3-, or 4-Wire
