Emerson PACSystems RSTi-EP - Resistance Measurement Range EP-3704

User Manual Section 5
GFK-2958L May 2021
Detailed Description of I/O Modules 355
5.32.6 Resistance Measurement Range EP-3704
Measurement
range
Resistance
Decimal
Hexadecimal
Range
40 Ω
> 47.04 Ω
32,767
0x7FFF
Overloading or line break
47.04 Ω
32511
0x7EFF
Overloading
40 Ω
27648
0x6C00
Nominal range
0
0
0x0000
80 Ω
> 94.07 Ω
32,767
0x7FFF
Overloading or line break
94.07 Ω
32511
0x7EFF
Overloading
80 Ω
27648
0x6C00
Nominal range
0
0
0x0000
150 Ω
> 176.4 Ω
32,767
0x7FFF
Overloading or line break
176.4 Ω
32511
0x7FFF
Overloading
150 Ω
27648
0x6C00
Nominal range
0
0
0x0000
300 Ω
> 352.77 Ω
32,767
0x7FFF
Overloading or line break
352.77 Ω
32511
0x7FFF
Overloading
300 Ω
27648
0x6C00
Nominal range
0
0
0x0000
500 Ω
> 587.9 Ω
32,767
0x7FFF
Overloading or line break
587.9 Ω
32511
0x7FFF
Overloading
500 Ω
27648
0x6C00
Nominal range
0
0
0x0000
1 kΩ
> 1.177 kΩ
32,767
0x7FFF
Overloading or line break
1.177 kΩ
32511
0x7FFF
Overloading
1.0 kΩ
27648
0x6C00
Nominal range
0
0
0x0000
2 kΩ
2.352 kΩ
32,767
0x7FFF
Overloading or line break
2.352 kΩ
32511
0x7FFF
Overloading
2.0 kΩ
27648
0x6C00
Nominal range
0
0
0x0000
4 kΩ
> 4.703 kΩ
32,767
0x7FFF
Overloading or line break
4.703 kΩ
32511
0x7FFF
Overloading
4.0 kΩ
27648
0x6C00
Nominal range
0
0
0x0000
