Emerson PACSystems RSTi-EP - Configuration of the IP Address; Modifiable Parameters for EPXMBE001;EPXMBE101

User Manual Section 4
GFK-2958L May 2021
Detailed Descriptions of the Fieldbus Network Adapters 100
Specification
Description
Storage temperature
-40°C to +85°C (-40 °F to +185 °F)
Air humidity (operation/transport)
5% to 95%, noncondensing as per IEC 61131-2
Width
52 mm (2.05 in)
Depth
76 mm (2.99 in)
Height
120 mm (4.72 in)
Weight
223 g (7.87 oz)
4.4.4 Configuration of the IP Address
The web server can be used to define whether a static IP address shall be used, or the address
shall be assigned automatically (DHCP/BootP).
Network adapters using firmware version 01.xx.xx are preset to the static IP address
192.168.0.222.
Network adapters using firmware version 02.00.00 or higher will by default send a DHCP
discover first. If no assignment by a DHCP server follows during the next 30 seconds, the
static IP address 192.168.0.222 will be set.
4.4.5 Modifiable Parameters for EPXMBE001/EPXMBE101
Parameter
Optional values
Default
IP-Address
#
4 numbers between 0-255
192.168.0.222
Subnet mask
#
4 numbers between 0-255
255.255.255.0
Gateway
#
4 numbers between 0-255
192.168.0.1
IP Configuration
#
Static, DHCP, BootP
DHCP and static
MODBUS DHCP Timeout
Waiting time, 1 to 1,000 s
30 s
Additional TCP port
1
0 (disabled) / Value from 1 to
65,535
†
(except for 80 and 161)
0
Modbus Dual LAN Mode
(EPXMBE101 only)
†
disabled / enabled
disabled
IP-Address USB Port†
192.168.1.202; 192.168.2.202,
192.168.3.202, 192.168.4.202,
192.168.5.202
192.168.1.202
Webserver via Ethernet
†
disabled / enabled
disabled
Save module parameters
2
no / yes / Standard
no, refer to register 0x113C – 0x113F Save
Module Parameters
Status Modbus watchdog
Watchdog time in steps of 10ms
0 *10ms, refer to register 0x1120 MODBUS
DATA EXCHANGE watchdog, predefined time
Modbus Connection
Timeout
Connection watchdog time in sec
1 s, refer to register 0x1131 MODBUS
CONNECTION Timeout in Sec
Write access in multi-client
operation
write for all, 1stWr1stServe,
1stConn1stServe
write for all, refer to register 0x1031 MODBUS
CONNECTION Mode Register
Check reference list before
exchanging data
disabled / enabled
disabled, refer to register 0x1132 Check
Reference List prior to Data Exchange
Process alarm
disabled / enabled
refer to register 0x1133 Process Alarm
Diagnostic alarm
disabled / enabled
refer to register 0x1134 Diagnostic Alarm
