Emerson PACSystems RSTi-EP - Modifiable Parameters for EP-3804

User Manual Section 5
GFK-2958L May 2021
Detailed Description of I/O Modules 361
5.33.3 Modifiable Parameters for EP-3804
Channel
Description
Options
Default
Temperature unit
Degree Celsius (0) /
Degree Fahrenheit (1) /
Degree Kelvin (2)
Degree Celsius
0 - 3
Measurement range
TC Type J (0) /
TC Type K (1) /
TC Type N (2) /
TC Type R (3) /
TC Type S (4) /
TC Type T (5) /
TC Type B (6) /
TC Type C (7) /
TC Type E (8) /
TC Type L (9) /
TC Type U (10) /
± 15.625 mV (11) /
± 31.25 mV (12) /
± 62.5 mV (13) /
± 125 mV (14) /
± 250 mV (15) /
± 500 mV (16) /
± 1,000 mV (17) /
± 2,000 mV (18) /
disabled (19)
disabled
0 - 3
Cold junction compensation
internal (0) /
external Channel 0 (1) /
external Channel 1 (2) /
external Channel 2 (3) /
external Channel 3 (4)
internal
0 - 3
Conversion time
240ms (0) /
130ms (1) /
80ms (2) /
55ms (3) /
43ms (4) /
36ms (5)
80ms
0 - 3
Channel diagnostics
disabled (0) / enabled (1)
disabled
0 - 3
Limit value monitoring
disabled (0) / enabled (1)
disabled
0 - 3
High limit value
-32,768 ... 32,767
0
0 - 3
Low limit value
-32,768 ... 32,767
0
