Emerson PACSystems RSTi-EP - Process Data Inputs EP-1813

User Manual Section 5
GFK-2958L May 2021
Detailed Description of I/O Modules 378
Name
Bytes
Bit
Description
Default
2
Reserved
0
3
Reserved
4
Reserved
5
Reserved
6
Reserved
7
Reserved
Channel 2 error
13
0
Voltage overrange (300V + 10%)
1
Current overrange (I + 10%)
0
2
Reserved
0
3
Reserved
4
Reserved
5
Reserved
6
Reserved
7
Reserved
Error in channel 3
14
0
Reserved
1
Reserved
0
2
Reserved
0
3
Reserved
4
Reserved
5
Reserved
6
Reserved
7
Reserved
Channel 4 error
to
Channel 31 error
15-42
0-7
Reserved
0
Time stamp
43-46
Time stamp [
μ
s] (32-bit)
5.34.5 Process Data
†
Inputs EP-1813
Byte
Format
Description
Remarks
IB0
Word
CH0
Channel 0
IB1
IB2
Word
CH1
Channel 1
IB3
IB4
Word
CH2
Channel 2
IB5
IB6
Word
CH3
Channel 3
IB7
IB8
Word
CH4
Channel 4
IB9
IB10
Word
CH5
Channel 5
IB11
