5.23.8 Network Adapters-Dependent Process data widths
The following tables show which process data lengths are available for the individual
adapters, and the relevant fieldbus-dependent data widths.
Profibus-EPXPBS001
Process data for IO-Link devices
IO-Link port
Network adapters
dependent data widths
1)
Input-byte
Output-byte
Input-byte
Output-byte
4
4
6
6
8
8
10
10
16
16
18
18
32
32
34
34
16
8
18
10
32
16
34
18
32
8
34
10
1)
incl. 2 Byte module process data
Profinet -EPXPNS001/EPXPNS101
Process data for IO-Link devices
IO-Link port
Network adapters dependent
data widths
1)
Input-byte
Output-byte
Input-byte
Output-byte
4
4
6
6
8
8
10
10
16
16
18
18
32
32
34
34
64
64
66
66
128
128
130
130
16
8
18
10
32
16
34
18
32
8
34
10
64
8
66
10
64
16
66
18
64
32
66
34
128
8
130
10
128
16
130
18
128
32
130
34
128
64
130
66
1)
incl. 2 Byte module process data
