5.8 Digital Output Module EP-2214
Figure 81: Digital Output
Module EP-2214
Figure 82: Connection Diagram EP-2214
The EP-2214 digital output module can control up to 4 discrete outputs, each with a
maximum of 0.5 A. One discrete output can be connected to each connector using a 2-
wire, 3-wire or 3-wire connection + FE. A status LED is assigned to each channel. The
outputs are supplied with power from the output current path (IOUT).
