Emerson PACSystems RSTi-EP - 5.11 Digital Output Module EP-2218

User Manual Section 5
GFK-2958L May 2021
Detailed Description of I/O Modules 169
5.7.2 Specifications EP-153F
Specification
Description
System data
Data
Process, parameter and diagnostic data depend on the network
adapter used (refer to Section, Order and Arrangement of
Modules
Interface
RSTi-EP I/O communication bus
System bus transfer rate
48 Mbps
Inputs
Number
16
Sensor types
N-Switching, comparable to Type 1 and Type 3 sensors as per IEC
61131-2
Input filter
Input delay 3ms
Low input voltage
< 5 V
High input voltage
> 11 V
Sensor supply
No
Sensor connection
1-conductor
Reverse polarity protection
Yes
Module diagnosis
Yes
Individual channel diagnosis
No
Supply
Supply voltage
20.4V – 28.8V
Current consumption from system current path
ISYS
8 mA
Current consumption from input current path IIN
52mA
General data
Weight
88 g (3.10 oz)
5.7.3 Diagnostic Data EP-153F
Name
Bytes
Bit
Description
Default
Error indicator
0
0
Module error
1
Internal error
2
External error
3
Channel error
0
4
Error
5
Reserved
0
6
Reserved
0
7
Parameter error
Module type
1
0
Module Type
0x0F
1
2
3
4
Reserved
0
5
Reserved
0
