Emerson PACSystems RSTi-EP - Process† Data Outputs EP-225 F

User Manual Section 5
GFK-2958L May 2021
Detailed Description of I/O Modules 191
5.12.4 Process† Data Outputs EP-225F
Byte
Bit
Description
OB0
OX0.0
DO0
OX0.1
DO1
OX0.2
DO2
OX0.3
DO3
OX0.4
DO4
OX0.5
DO5
OX0.6
DO6
OX0.7
DO7
OB1
OX1.0
DO8
OX1.1
DO9
OX1.2
DO10
OX1.3
DO11
OX1.4
DO12
OX1.5
DOI13
OX1.6
DO14
OX1.7
DO15
†
Internal process data mapping with data format “Standard”.
Depending on the fieldbus specification and the data format of the
communicating fieldbus components the bytes and/or words can be
reversed during data transfer.
