Emerson PACSystems RSTi-EP - 0 X1000 - 0 X1006 Network Adapter Identifier; 0 X1000 - 0 X1006 Network Adapter Status; 0 X1010 Process Image Length in Bits for the Output Modules; 0 X1010 Process Image Length in Bits for the Input Modules

User Manual Section 4
GFK-2958L May 2021
Detailed Descriptions of the Fieldbus Network Adapters 108
Module
Process data
Input
Output
EP-1813
8 Word
8 Word
EP-1901
4 Byte
--
EP-1922
4 Byte
--
EP-1902
Byte
--
4.4.8 0x1000 – 0x1006 Network Adapter Identifier
The identifier is the product designation: EPXMBE001 and EPXMBE101 as per Network
adaptor Catalog number.
4.4.9 0x1000 – 0x1006 Network Adapter Status
Bit
Name
Meaning
0
Summarized module
diagnosis
A diagnosis is available on at least one module with diagnostics functionality.
1
Errorbit 1
Reserve bit 1, currently not used
2
Errorbit 2
Reserve bit 2, currently not used
3
System bus error
Error on system bus. Communication with the connected modules is disrupted.
4
Errorbit 4
Reserve bit 4, currently not used
5
Errorbit 5
Reserve bit 5, currently not used
6
I/O-Configuration error
Differing configuration. The module list has changed. The list of configured
modules (reference module list 0x2800 – 0x287F) differs from the module list
detected by the network adapter (current module list 0x2A00 – 0x2A7F).
7
Master configuration error
Master configuration error. The list of configured modules (reference module list
0x2800 – 0x287F) differs significantly from the module list detected by the
network adapter (current module list 0x2A00 – 0x2A7F). Process data cannot be
exchanged with the modules.
8
Errorbit 8
Reserve bit 8, currently not used
9
Errorbit 9
Reserve bit 9, currently not used
10
Force mode active
Force mode was activated via the web server.
Forced channels do not exchange data with the master.
11
Errorbit 11
Reserve bit 11, currently not used
12
Errorbit 12
Reserve bit 12, currently not used
13
Voltage UOUT error
Error in the supply voltage of outputs
14
Voltage UIN error
Error in the supply voltage of system and inputs
15
Errorbit 15
Reserve bit 15, currently not used
4.4.10 0x1010 Process Image Length in Bits for the Output
Modules
4.4.11 0x1010 Process Image Length in Bits for the Input
Modules
4.4.12 0x1017 Register – Mapping Revision
